IPTV SET-TOP BOX MAG349
MAG349 is a premium IPTV/OTT Set-Top Box by Infomir, a European manufacturer. It is targeted to the operators’ market and provides interactive TV services over IP-based networks (IPTV, VoD, OTT). This device comes with the most advanced features, making its performance extraordinary. A larger RAM and heavy-duty processor allow you to enhance the velocity of STB. HEVC technology, used in MAG349, requires smaller network bandwidth for provision of video of higher quality. MAG349is equipped with dual-band Wi-Fi and ultimate Bluetooth adaptors that provide additional connection opportunities.
HEVC support. Powerful media processor and Broadcom chipset with 6000 DMIPS performance. Built-in Wi-Fi 2.4GHz/5GHz(ac) and Bluetooth 4.0 adaptors.
New model MAG
Specifications
| Width/depth/height, mm | 132x87x26 |
| Weight, g | 137 |
| Chipset | BCM7250 |
| Processor | ARM A15 (B15) Core CPU 1.2 GHz |
| Performance | 6000 DMIPS |
| RAM | 1 GB |
| Flash memory | 8 GB |
| Operating system | Linux 3.3 |
| Built-in Media Portal with WebKit-based IPTV-functionality, HTTP 1.1, HTML 4.01 XHTML 1.0/1.1; DOM 1, 2, 3, CSS 1, 2, 3; XML 1.0, XSLT 1.0, XPath 1.0 ; SOAP 1.1; JavaScript; ECMA-262, revision 5; Media JavaScript API; C layer SDK | |
| DRM option | Secure Media |
| Middleware supported | Ministra TV-platform, SoftAtHome |
| HDMI 1.4a-output, Composite + stereo A/V output, Audio output S/PDIF, Ethernet 1 Gb/s, 2* USB 2.0 (Wi-Fi adapter can be connected), Built-in Wi-Fi 2.4 GHz/5 GHz ac (optional) |
| PC and NAS in local networ, Stream media protocols (RTSP, RTP, UDP, HTTP), USB-devices |
| Audio сodecs | MPEG-1 layer I/II, MPEG-2 layer II, MPEG-2 layer III (mp3), Dolby Digital, AAC-LC, HE-AAC v1, HE-AAC v2 |
| Audio formats | MP3, MPA, M4A, OGG, WAV |
| Video modes | 1080i, 1080p, 720p, 576p, 480р, PAL, NTSC |
| Video сodecs | MPEG1/2 MP@HL, H.264 HP@level 4.1, H.265 (HEVC), MPEG4 part 2 (ASP), WMV-9 (optional), XviD; 3D and HD video supporting |
| Video containers | MKV, MPEG-TS, MPEG-PS, M2TS, VOB, AVI, MOV, MP4, ASF, QT, WMV |
| Image formats | JPEG, PNG, BMP, GIF, RAW |
| Subtitles | ttxt sub*, DVB, WebVtt, PGS, Ass/Ssa*, Srt*, Sub*, Closed captions |
| Playlist formats | M3U |
| MAG349 Set-Top Box, HDMI cable, Remote control, 2 AAA batteries, packaging, Power adapter 12 V 1 A, User manual |
New generation of MAG Set-Top Boxes
